Specification

• Model

  GP-M220RF

• Print Method

  Direct thermal

• Print Command

  ESC/POS

• Resolution

  203DPI

• Print Speed

  40-70mm/S Auto-Speed Adjustment

• Print Width

  48mm

• Overheat Protection

  Thermistor

• Media Detection

  Thru Beam Sensor, reflective sensor

• Sensor Position

  Left

• Memory

  RAM:256k FLASH:1M

• Button

  Power button, Feed button

• Interface

  USB+Bluetooth

• USB Type

  Type-C

• USB VID PID

  VID：0471, PID：0055

• Graphics

  Monochrome PCX, BMP and other image file printing

• Media Type

  Thermal paper, label paper, reverse black mark paper

• Media Width

  58mm

• Media Thickness

  0.06mm-0.17mm

• Media Roll Outer Diameter

  50mm

• Media Output

  Top paper output

• Power Supply

  Input：DC 5V 2A

• Charging Time

  ≤2h

• Battery Standby Time

  ≥72h

• Battery Print Mileage

  ≥200m（12.5% printing rate）

• Battery Cycle Life

  500times，≥80%

• Battery Capacity

  7.4V/1500mAh

• Working Environment

  5~40℃，20~90%non-condensing

• Storage Environment

  -25~55℃，20~93%non-condensing

• Pressure

  86~106kPa

• Printer N.W (with battery)

  265g

• Printer Dimensions

  88mm x 126mm x 63mm

• Packing Dimension

  98mm×155mm×75mm

• Box Dimension

  330mm×320mm×260mm

• Quantity/Box（PSC）

  18

• Box Weight（KG）

  7KG

• Print Head (reliability)

  30km

• Printer Certificate

  CCC、SRRC、UN38.3
