Specification

• Model

  GP-M220F

• Print Method

  Direct thermal

• Print Command

  Custom command

• Resolution

  203 DPI

• Print Speed

  40-70mm/S Auto-Speed Adjustment

• Print Width

  48mm

• Overheat Protection

  Thermistor

• Media Detection

  Reflective sensor

• Sensor Position

  Left

• Memory

  RAM:256k, FLASH:1M

• Button

  FEED/POWER

• Interface

  USB+Bluetooth

• USB Type

  Type-C

• USB VID PID

  VID：0471 PID：0055

• Graphics

  Monochrome PCX, BMP and other image file printing

• Media Type

  Continuous、Label Paper

• Media Width

  25-58mm

• Media Thickness

  0.06mm-0.17mm

• Media Roll Outer Diameter

  50mm

• Media Output

  Top paper output

• Power Supply

  Input：DC 5V 2A

• Charging Time

  ≤2h

• Battery Standby Time

  ≥72h

• Battery Print Mileage

  ≥200m（12.5% printing rate）（25℃）

• Battery Cycle Life

  500times，≥80%

• Battery Capacity

  7.4V/1500mAh

• Working Environment

  5~40℃，20~90%non-condensing

• Storage Environment

  -20~55℃，20~93%non-condensing

• Pressure

  86~106kPa

• Printer N.W (with battery)

  265g

• Printer Dimensions

  88mm × 126mm × 63mm

• Packing Dimension

  98mm × 155mm × 75mm

• Box Dimension

  330mm × 320mm × 260mm

• Quantity / Box（PSC）

  18

• Box Weight（KG）

  7KG

• Print Head (reliability)

  30km

• Printer Certificate

  CCC、SRRC、UN38.3
