Overview

Specification

• Print method

  Direct thermal

• Dot density

  /

• Print width

  104mm max.

• Resolution

  203 DPI

• Print speed

  35mm/s

• Interface

  USB + Bluetooth (USB+Wi-Fi Optional)

• Paper width

  25mm-112mm(±0.5mm)

• Paper diameter

  OD 50mm max.; ID 9mm max.

• Paper thickness

  0.06mm-0.17mm

• Print commands

  TSPL，CPCL，ESC/POS

• Fonts

  /

• Character Size

  Simplified Chinese：16×16 20×20 24×24 32×32； Traditional Chinese：24×24; Korean：24×24

• Barcode mode

  1D: CODE128, EAN128, ITF, CODE39, CODE93, EAN13, EAN13+2, EAN13+5, EAN8, EAN8+2, EAN8+5, CODABAR, POSTNET, UPC-A, UPC-A+2, UPC-A+5, UPC-E, UPC-E+2, UPC-E+5, CPOST, MSI, MSIC, PLESSEY, ITF14, EAN14 2D: QRCODE

• Code page

  /

• Dimension

  123(L) x 140(W) x 61(H)mm

• Weight(including battery)

  542 g

• Power adaptor

  DC 5V, 2A

• Lithium battery

  3000mAh, 7.4V

• Charge period

  > 4 hour

• Work environment

  5~45℃℃(41~104OF), 25~85%

• Storage environment

  -10~50℃℃(-10~140OF), 10~90%

• Drop resistance

  /

• Mechanism

  30KM
