80mm Thermal Receipt Printer GA-E200I

Thermal receipt printer

Product Features

•200mm/s printing speed, up to 250mm/s high-speed printing
•The printing command protocol is based on the ESC/POS standard mode
•Support CODE128, QRCODE and other barcode printing
• Equipped with USB, Ethernet port, RJ11 cash box communication interface
•Suitable for restaurants, takeout orders, stores, supermarkets, hotels and other scenarios and applications

Application Industries

Medical Insurance
Retail
Entertainment And Service Industry

Consult now

Overview Specification Download Operation film FAQ Contact

Overview

Specification

Printer Model

GA-E200I
Print Method

Direct thermal line
Emulation

ESC/POS
Paper width

58/80 mm
Print width

72mm
Resolution

8dots/mm(203DPI)
Paper roll

83mm diameter max.
Print speed

200mm/second
Paper thickness

0.06～0.08mm
Interface

1. USB+RJ11 CashDrawer
2. ETH+RJ11 CashDrawer
3. USB+ETH+RJ11 CashDrawer
Data buffer

64K SRAM, 256K Flash
Barcode type

UPC-A/UPC-E/JAN13(EAN13)/JAN8(EAN8)/CODE39/ITF/CODEBAR/CODE93/CODE128/QRCODE
Power supply

Input: AC 110V/220V, 50~60Hz
Output: DC 24V/1.5A
Cash drawer

DC 24V 1A
Print head life

150KM
Auto cutter life

1.5 million times
Operating system

Support Windows driver
Net Weight

0.8kg
Dimension

130mm（D）x 161mm（W）x 126mm(H)
