Overview

Introduction

Efficient label management is crucial in modern warehouse operations.  Heavy-duty ribbon barcode printers have become the perfect solution for warehouse label management, enhancing label durability, readability, and management efficiency.

Advantage

1. Wear-Resistant Labels: Heavy-duty ribbon barcode printers can generate wear-resistant labels capable of withstanding the daily wear and tear in warehouse environments, ensuring long-term readability.
Improving Readability
2. High-Speed Printing: They feature high-speed printing capabilities, enabling the efficient production of a large number of labels in a short time.
1. Automated Label Generation: These printers can integrate with warehouse management systems to achieve automated label generation, reducing the time and potential errors associated with manual label creation.
Cost Reduction

1. Reduced Label Replacement Frequency: Due to their durability, these labels require less frequent replacement, reducing label maintenance costs.

2. Error Reduction: Automated label generation reduces human errors, such as misdirected goods or unclear labels, lowering additional costs.

Heavy-duty ribbon barcode printers offer comprehensive solutions for warehouse label management. They enhance label durability, readability, and management efficiency, reducing label maintenance and replacement costs, and contributing to improved warehouse operations' efficiency and accuracy. These printers are becoming indispensable tools in modern warehouse management, ensuring label stability and reliability in demanding environments.

Specification

• MODEL

  GI-2408T PLUS
  GI-3406T PLUS

• Level

  Standard

• Resolution

  GI-2408T PLUS: 8 dots/mm (203DPI)
  GI-3406T PLUS: 12 dots/mm (300DPI)

• Printing Method

  Thermal Transfer & Direct Thermal

• Max. print speed

  GI-2408T PLUS: 203mm(8")/second
  GI-3406T PLUS: 152mm(6")/second

• Max. print width

  GI-2408T PLUS: 102 mm (4")
  GI-3406T PLUS: 106.9 mm (4.2")

• Max. print length

  GI-2408T PLUS: 2,286mm (90")
  GI-3406T PLUS: 1,016mm (40")

• CPU

  400 MHZ, 32 bits, ARM9

• Memory RAM

  128 MB SDRAM

• Memory ROM

  128 MB Flash Memory

• Interface

  • USB 2.0 High Speed 480Mbps
  • USB Host 2.0, for scanner or PC keyboard
  • RS-232
  • Internal Ethernet 10/100Mbps
  • Internal Bluetooth 4.0 (factory option)
  • Internal WiFi (factory option)
  • I/O port (factory option)

• Real Time Clock

  Standard

• Buzzer

  Standard

• Dealer options

  • Guillotine cutter (full cut or partial cut)
  • Peeler

• Sensors

  • Gap transmissive sensor (position adjustable)
  • Black mark reflective sensor (position adjustable)
  • Head open sensor
  • Ribbon out sensor
  • Label begin sensor

• Power

  Internal universal switching power supply
  Input: AC 100-240V, 1.5A, 50-60Hz, Output: DC 24V, 5A, 120W

• User Interface

  • 1 power switch
  • 2 buttons (Feed & Pause)
  • 4 LEDs (Online, Error, Ribbon, Communication status)

• Internal fonts

  • 8 alpha-numeric bitmap fonts
  • True type font engine (need download scalable font file)

• 1D Barcode

  Code 11, Code 39, Code 93, Code 128 (subsets A, B, C), UPC-A, UPC-E, UCC-128, Codabar, EAN/JAN-8, EAN/JAN-13, Interleaved 2 of 5, ITF14, MSI Pleassy, PostCode, Telepen

• 2D Barcode

  QR Code, Micro QR Code, PDF417, Micro PDF417, MaxiCode, Aztec Code, Data Matrix

• Rotation

  Font and barcode support 0, 90, 180, 270 degree

• Printer language

  Compatible to TSPL, EPL, ZPL, ZPL II, DPL

• Ribbon

  450 M long, max. OD 105 mm, 1" core (ink coated outside)

• Ribbon width

  Max.110mm (4.3")

• Media type

  Continuous, die-cut, black mark, fan-fold (outside wound)

• Media width

  20~120 mm(0.78"~4.72")

• Media thickness

  0.06~0.254mm (2.36~10mil)

• Media core diameter

  25.4mm~76.2mm (1"~3")

• Label roll capacity

  203mm (8") OD

• Label length

  GI-2408T PLUS: 5 ~ 2,286mm (0.2" ~ 90")
  GI-3406T PLUS: 5 ~ 1,016mm (0.2" ~ 40")

• Physical dimension

  444mm(L)*269mm(W)*339mm(H)

• Net Weight

  12.8kg

• Enclosure

  Die-cast based print mechanism/Metal cover with large clear media view window

• Safety regulation

  FCC Class A (Voltage specification is 110V, 200V is not supported), CE Class A, CCC, BIS, CB

• Environment condition

  Operation: 5 ~ 40°C, 25 ~ 85% non-condensing
  Storage: -40 ~ 60°C, 10 ~ 90% non-condensing

• Environmental concern

  Comply with RoHS, REACH, WEEE

• Accessories

  • Windows labeling software CD disk
  • Quick start guide
  • USB cable
  • Power cord

Operation film
