Overview

Specification

• Printer Model

  GP-1225Z

• Print Method

  Thermal Transfer / Direct Thermal

• Print Speed(inch/s)

  2~6inch/s

• Interface

  Serial+USB+Parallel+Ethernet

• Print Resolution

  203dots/inch(8dots/mm)

• Print Density

  0.125×0.125 mm (1 mm = 8 dots)

• Print Width

  108 mm(4.25")

• Print Length

  2286 mm(90")

• Print Head

  50KM

• Printer Dimensions

  285mm(L) x 210mm(W) × 180mm(H)

• Print Weight

  2.09KG

• Memory

  Ram: 4MB Flash: 8MB

• Font Size

  0.125×0.125 mm (1 mm=8 dots)

• Power supply

  Input: AC 110-240V
  Output: DC 24V 2.5A，60W

• Media Roll Diameter

  1 inch (25.4 mm)

• Media Width

  Max.120 mm(4.72") Min.20 mm(0.78")

• Media Roll Core Size

  25.4 mm~38 mm(1"~1.5")

• Media type

  Continuous paper, paper with inter spaces, folding paper, black mark paper

• Media rolling up method

  Printing side outward rolling / inward rolling

• Media Length

  2286 mm(0.39"~90")
  Remark: If label length less than 25.4mm(1 inch), label paper with perforations are recommended, labels can be torn off easily

• Ribbon Diameter

  Max. 67 mm

• Ribbon Length

  300m

• Ribbon Core Size

  1 inch (25.4 mm)

• Ribbon Width

  Max. 110 mm Min. 30 mm

• Enlargement&Rotation

  25.4 mm~38 mm(1"~1.5")

• Work environment

  5~45℃(41~113°F), 25~85% non-condensing

• Storage environment

  -10~50℃(14~122°F), 10~90% non-condensing

• Emulation

  ZPL
