Overview

Introduction

Supermarkets are at the core of the fast-paced retail industry, and direct thermal barcode mini printers are becoming a valuable tool in supermarket operations.

Advantage

1. High-Speed Printing: Mini Direct thermal label printers are known for their high-speed printing capabilities, enabling the instant creation of clear price labels. This means supermarket staff can quickly update and replace labels, ensuring the accuracy of product prices.
2. Real-time Price Adjustments: These printers can generate price labels on-the-fly to accommodate special promotions or price changes, ensuring that supermarkets can rapidly respond to market shifts.
Streamlining Inventory Management:
1. Automated Inventory Tracking: Mini Direct thermal label printers can generate labels with unique barcodes, which are used for inventory management. Staff can easily scan these labels to track inventory and ensure that the products on the shelves are in sync with the stock.
2. Preventing Inventory Errors: By using labels and barcode systems, supermarkets can reduce inventory errors, ensuring product accuracy and availability.
Enhancing Customer Experience:
1. Clear and Readable Labels: High-resolution printing ensures that price labels and product information are clear and readable, helping customers quickly understand product details.
2. Providing Custom Labels: These printers can generate labels with supermarket brand identification and special information, enhancing the market appeal of products.
Cost Savings:
1. Reduced Printing Costs: These printers offer efficient price label generation, reducing the costs of printing and label replacement.
2. Reducing Errors: The automated label generation process reduces human errors, such as handwritten labels or input mistakes.
Mini Direct thermal label printers are playing a vital role in supermarket operations. They improve the speed of price label printing, simplify inventory management, enhance the customer experience, and reduce the costs of printing and label replacement. By provi

Specification

• PRINTER MODEL

  GE-2408D

• Grade

  Standard / Empower

• Resolution

  203DPI

• Printing Method

  Direct Thermal

• Max. print speed

  8"/second

• Max. print width

  104mm(4.1")

• Max. print length

  10 ~ 1000 mm (0.39"~39.37")

• CPU

  Standard：400 MHZ, 32 bits,Cotext-M7
  Empower：400 MHZ, 32 bits, ARM9

• Memory RAM

  Standard：8 MB PSRAM
  Empower：128 MB SDRAM

• Memory ROM

  Standard：16 MB Flash Memory
  Empower：128 MB Flash Memory

• Interface

  Standard：USB 2.0 High Speed 480Mbps ； BT(Support 1BLE+7SPP connection ) option ； BT+2.4G WiFi （BT 1BLE+1SPP， WiFi only 2.4G）option；5G+2.4G WiFi option
  Empower：USB 2.0 High Speed 480Mbps；USB Host 2.0；RS-232；Internal Ethernet 10/100Mbps

• Sensors

  Head open sensor, Ribbon end sensor, Reflective sensor (moveable), Transmissive sensor

• Power

  External universal switching power supply
  Input: AC 100-240V, 2.5A, 50-60Hz, Output: DC 24V, 2.5A, 60W

• User Interface

  Standard：1 power switch, 1 button (Feed & Pause), 5 LEDs (Online white, Error red, Label green, Bluetooth blue, WIFI blue)
  Empower：1 power switch, 1 button (Feed & Pause), 5 LEDs (Online white, Error red, Label green, Bluetooth blue, WIFI & Communica

• Internal fonts

  • 8 alpha-numeric bitmap fonts
  • True type font engine (need download scalable font file)
  • GB18030 Simplified Chinese 24x24, 16x16
  • BIG5 traditional Chinese 24x24, 16x16

• 1D Barcode

  Code 11, Code 39, Code 93, Code 128 (subsets A, B, C), UPC-A, UPC-E, UCC-128, Codabar, EAN/JAN-8, EAN/JAN-13, Interleaved 2 of5, ITF14, MSI Pleassy, PostCode, Telepen

• 2D Barcode

  QR Code, Micro QR Code, PDF417, Micro PDF417, Grid Matrix, MaxiCode, Aztec Code, Data Matrix

• Rotation

  Font and barcode support 0, 90, 180, 270 degree

• Printer language

  TSPL, EPL, ZPL, ZPL II, DPL

• Ribbon

  /

• Ribbon width

  /

• Media type

  Continuous, die-cut, black mark, fan-fold, notched

• Media width

  104mm(4.1")

• Media thickness

  0.06~0.19mm (2.34~7.4 mil)

• Media core diameter

  25.4mm~38mm (1"~1.49")

• Label roll capacity

  127 mm (5") OD

• Label length

  10 ~ 1000 mm (0.39"~39.37")

• Physical dimension

  243.5mm(D) x 194.5mm(W) x 184mm(H)

• Net Weight

  2KG

• Enclosure

  ABS plastic

• Safety regulation

  FCC Class A, CE Class A, CCC, CB

• Environment condition

  Operation: 5~40°C, 25~85% non-condensing
  Storage: -40~ 60°C, 10~90% non-condensing

• Environmental concern

  Comply with RoHS, REACH, WEEE

• Accessories

  • Windows labeling software CD disk
  • Quick start guide
  • USB cable
  • Power cord
  • External universal switching power supply
