Overview

Advantage

A Budget-Friendly Option:
1. Affordable Pricing: Affordable thermal printers typically come with relatively low price tags, making them an ideal choice for small retail businesses and startups.
2. Low Maintenance Costs: These printers are often easy to maintain, reducing the costs associated with repairs and consumables replacement.
Meeting Basic Needs:
1. Price Label Printing: Affordable thermal printers are adequate for the basic needs of retailers, including price label and sales receipt printing.
2. Basic Functionality: They offer essential printing functions suitable for the day-to-day requirements of small-scale retail operations.
Applicability and Limitations:
1. Suitable for Small Retailers: These printers are an economically viable choice for small retailers or budding entrepreneurs, meeting their fundamental printing needs.
2. Limited Advanced Features: However, affordable thermal printers usually lack some advanced features like high-resolution printing or complex connectivity options.
3. Not Suitable for Large-Scale Retailers: For large-scale retailers or businesses requiring advanced functionality, budget-friendly thermal printers may not suffice.
Affordable thermal printer are a smart choice for the retail industry, particularly well-suited for small retailers and startups. They provide basic functionalities while reducing costs. However, for large retailers or businesses in need of advanced features, considering higher-end printing solutions may be necessary. In the retail sector, ensuring that the chosen printer aligns with specific needs is crucial to strike a balance between benefits and costs.

Specification

• PRINTER MODEL

  GE-2406T
  GE-3405T

• Grade

  Standard

• Resolution

  GE-2406T: 8dots/mm (203DPI)
  GE-3405T: 12dots/mm (300DPI)

• Printing Method

  Thermal Transfer & Direct Thermal

• Max. print speed

  GE-2406T: 152 mm (6")/second
  GE-3405T: 127 mm (5")/second

• Max. print width

  GE-2406T: 104 mm (4.1")
  GE-3405T: 108.4 mm (4.27")

• Max. print length

  GE-2406T: 2,794 mm (110")
  GE-3405T: 1,016 mm (40")

• CPU

  400 MHZ, 32 bits, ARM9

• Memory RAM

  64 MB SDRAM

• Memory ROM

  16 MB Flash Memory

• Interface

  • USB 2.0 High Speed 480Mbps
  •USB Host 2.0, for scanner or PC keyboard

• Sensors

  Head open sensor, Ribbon end sensor, Reflective sensor (moveable), Transmissive sensor

• Power

  External universal switching power supply
  Input: AC 100-240V, 2.5A, 50-60Hz, Output: DC 24V, 2.5A, 60W

• User Interface

  1 power switch, 1 button (Feed & Pause), 5 LEDs (Online white, Error red, Ribbon green, Bluetooth blue, WIFI & Communication orange)

• Internal fonts

  • 8 alpha-numeric bitmap fonts
  • True type font engine (need download scalable font file)
  • GB18030 Simplified Chinese 24x24, 16x16
  • BIG5 traditional Chinese 24x24, 16x16

• 1D Barcode

  QR Code, Micro QR Code, PDF417, Micro PDF417, MaxiCode, Aztec Code, Data Matrix

• 2D Barcode

  Code 11, Code 39, Code 93, Code 128 (subsets A, B, C), UPC-A, UPC-E, UCC-128, Codabar, EAN/JAN-8, EAN/JAN-13, Interleaved 2 of 5, ITF14, MSI Pleassy, PostCode, Telepen

• Rotation

  Font and barcode support 0, 90, 180, 270 degree

• Printer language

  Compatible to TSPL, EPL, ZPL, ZPL II, DPL

• Ribbon

  110 M long, max. OD 40mm, 0.5" core (ink coated outside)

• Ribbon width

  40mm~110mm (1.57"~4.3")

• Media type

  Continuous, die-cut, black mark, fan-fold, notched (outside wound)

• Media width

  20~118mm (0.7"~4.6")

• Media thickness

  0.06~0.19mm (2.34~7.4 mil)

• Media core diameter

  25.4mm~38mm (1"~1.49")

• Label roll capacity

  127 mm (5") OD

• Label length

  GE-2406T: 5~2,794 mm(0.2"~110") GE-3405T: 5~1,016 mm(0.2"~40")

• Physical dimension

  225mm(D) x 194.5mm(W) x 184mm(H)

• Net Weight

  1.5kg

• Enclosure

  ABS plastic

• Safety regulation

  FCC Class A, CE Class A, CCC, BIS, CB

• Environment condition

  Operation: 5~40°C, 25~85% non-condensing Storage: -40~ 60°C, 10~90% non-condensing

• Environmental concern

  Comply with RoHS, REACH, WEEE

• Accessories

  • Windows labeling software CD disk
  • Quick start guide
  • USB cable
  • Power cord
  • External universal switching power supply
