Desktop Barcode Printer

4-inch panel printers are compact printing devices that are commonly used in various applications where space is limited. These printers feature a narrow width of approximately 4 inches, allowing them to fit easily into small spaces and integrate seamlessly into different systems and environments.

Here are some common applications where 4-inch panel printers are used:

Point of Sale (POS) Systems: 4-inch panel printers are widely used in retail and hospitality industries for printing receipts and invoices at the point of sale. They can be connected to cash registers, POS terminals, or mobile devices to provide fast and efficient printing capabilities.

Ticketing and Labeling: These printers are ideal for ticketing applications, such as printing event tickets, transportation tickets, parking passes, and more. They can also be used for printing labels in various industries, including logistics, healthcare, and manufacturing.

Self-Service Kiosks: 4-inch panel printers are commonly integrated into self-service kiosks for printing tickets, coupons, boarding passes, and other types of transactional documents. They enable users to obtain physical copies of their information or transactions quickly and conveniently.

Gaming and Lottery Machines: In gaming and lottery industries, 4-inch panel printers are used for printing tickets, vouchers, and receipts for players. These printers can handle high-volume printing requirements and provide reliable performance in gaming establishments.

Medical and Healthcare Applications: Panel printers find applications in healthcare settings, such as printing patient wristbands, prescription labels, test results, and medical records. They are designed to meet the specific requirements of the healthcare industry, including compliance with privacy regulations.

Industrial Automation: 4-inch panel printers are utilized in industrial automation systems for printing barcodes, shipping labels, product tags, and other identification labels. They play a crucial role in streamlining operations and improving efficiency in warehouses, manufacturing facilities, and distribution centers.

Transportation and Logistics: These printers are commonly used in transportation and logistics operations for printing shipping labels, delivery receipts, and invoices. They facilitate accurate tracking and documentation of goods during the supply chain process.

Specification

• Level

  Empower

• Resolution

  GA-2408T: 8 dots/mm (203DPI)
  GA-3406T: 12 dots/mm (300DPI)

• Printing Method

  Thermal Transfer & Direct Thermal

• Max. print speed

  GA-2408T: 203mm(8")/second
  GA-3406T: 152mm(6")/second

• Max. print width

  GA-2408T: 104 mm (4.09")
  GA-3406T: 106.7 mm (4.2")

• Max. print length

  GA-2408T: 25,400 mm (1,000")
  GA-3406T: 11,430 mm (450")

• CPU

  400 MHz, 32 bits, ARM9

• Memory RAM

  128 MB SDRAM

• Memory ROM

  128 MB Flash

• Interface

  • USB 2.0 High Speed 480Mbps
  • USB Host 2.0, for scanner or PC keyboard
  • Ethernet 10/100Mbps
  • RS-232
  • Internal Bluetooth 4.0 (factory option)
  • Internal Wi-Fi (factory option)

• Real Time Clock

  Standard

• Buzzer

  Standard

• Dealer options

  • Guillotine cutter
  • Guillotine cutter for Linerless thermal label
  • Peeler

• Sensors

  • Head open sensor
  • Ribbon out sensor
  • Reflective sensor (moveable)
  • Transmissive sensor (moveable)
  • Guillotine cutting system with a peel-off sensor

• Power

  External universal switching power supply
  Input: AC 100-240V, 2.5A, 50-60Hz. Output: DC 24V, 2.5A, 60W

• User Interface

  • 1 power switch
  • 1 button (Feed)
  • 1 LED (Blue & Red status)
  • Capacitive Touch Screen, TFT LCD 4.3" 16 bits Color, 480 x 272 pixels, with back lights

• Internal fonts

  • 8 alpha-numeric bitmap fonts
  • True type font engine (need to download scalable font file)

• 1D Barcode

  Code 11, Code 39, Code 93, Code 128 (subsets A, B, C), UPC-A, UPC-E, UCC-128, Codabar, EAN/JAN-8, EAN/JAN-13, Interleaved 2 of 5, ITF14, MSI Pleassy, PostCode, Telepen

• 2D Barcode

  QR Code, Micro QR Code, PDF417, Micro PDF417, MaxiCode, Aztec Code, Data Matrix

• Rotation

  Font and barcode support 0, 90, 180, 270 degree rotation

• Printer language

  Compatible to TSPL, EPL, ZPL, ZPL II, DPL

• Media type

  Continuous, die-cut, black mark, fan-fold (outside wound), linerless thermal label

• Media width

  20~118 mm (0.7" ~ 4.6")

• Media thickness

  0.06~0.254mm (2.36 ~ 10 mil)

• Media core diameter

  25.4 mm (1")

• Label roll capacity

  127 mm (5") OD

• Label length

  GA-2408T: 5 ~ 25,400 mm (0.2'' ~ 1000")
  GA-3406T: 5 ~ 11,430 mm (0.2" ~ 450")

• Physical dimension

  280mm(L) x 190mm(W) x 198.3mm(H)

• Net Weight

  2.8kg

• Enclosure

  Clamshell with double-walled plastic

• Ribbon

  300 meters long, max. OD 67 mm, 1" core (ink coated outside)

• Ribbon width

  30~110mm (1.18"~4.3")

• Safety regulation

  FCC Class A，CE Class A，CCC，BIS，CB

• Environment condition

  Operation: 5 ~ 40°C, 25 ~ 85% non-condensing
  Storage: -40 ~ 60°C, 10 ~ 90% non-condensing

• Environmental concern

  Comply with RoHS, REACH, WEEE

Operation film

• 21

  March

  4" Barcode Printer(TT)



  APEX SERIES: Product Overview

  GA-2408T(GA-3406T) (Standard/Empower)

• 21

  March

  4" Barcode Printer(TT)



  APEX SERIES: Install Peeler

  GA-2408T(GA-3406T) (Standard/Empower)

• 21

  March

  4" Barcode Printer(TT)



  APEX SERIES: Install Cutter

  GA-2408T(GA-3406T) (Standard/Empower)

• 21

  March

  4" Barcode Printer(TT)



  APEX SERIES: Replace Printhead

  GA-2408T(GA-3406T) (Standard/Empower)

• 21

  March

  4" Barcode Printer(TT)



  APEX SERIES: Ethernet setting

   GA-2408T(GA-3406T) (Standard/Empower)

• 21

  March

  4" Barcode Printer(TT)



  APEX SERIES: STA Set

  GA-2408T(GA-3406T) (Standard/Empower)
